Intel Core i7-13700F 2.1 GHz 16-Core LGA 1700 Processor

Power up your productivity, gaming, and content creation with the Intel Core i7-13700F 2.1 GHz 16-Core LGA 1700 Processor. This 13th generation desktop processor builds upon the Hybrid Core architecture and Intel 7 process by fitting 16 cores— four more than the previous generation— onto a single processor while still supporting the LGA 1700 socket. Designed to provide high performance, the Core i7-13700F features eight low-voltage Efficient-cores that handle background tasks for multitasking while the eight 2.1 GHz Performance-cores provide speed for demanding applications and games. The built-in Intel Thread Director ensures that the two work seamlessly together by dynamically and intelligently assigning workloads to the right core at the right time.

With 30MB of cache and a 5.2 GHz Turbo Boost Max 3.0 frequency, this processor is made to handle intense workloads. The Core i7-13700F also supports PCI Express 5.0 and dual-channel DDR5 memory at 5600 MHz.

The Core i7-13700K does not include integrated graphics, meaning that users will need to purchase a separate dedicated graphics card. This processor has a 65W TDP (Thermal Design Power) and includes an Intel Laminar RM1 cooling solution. This processor is backed by a 3-year warranty.

Hybrid Core Design

Performance-cores provide the speed to handle high-end games and demanding applications while low-priority and background tasks are handled by the processor's Efficient-cores for multitasking.

Intel Thread Director

The Intel Thread Director is built into the CPU's cores, working with the operating system to ensure each of the 24 threads are assigned to the right core at the right time.

PCIe 4.0 & 5.0

This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.

Gaussian & Neural Accelerator 3.0

Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats.

Intel Deep Learning Boost

Accelerates AI inference to improve performance for deep learning workloads.



Key Features

• 16 Cores & 24 Threads
• 2.1 GHz P-Core Clock Speed
• 5.2 GHz Maximum Turbo Boost Frequency
• LGA 1700 Socket
• 30MB Cache Memory
• Dual-Channel DDR5-5600 Memory
• Hybrid Core Architecture
• Includes Intel Laminar RM1 Cooler
• 13th Generation (Raptor Lake)





Key Specs



CPU Model	Intel Core i7-13700F (13th Gen)
CPU Socket	LGA 1700
Unlocked	No
Number of Cores	16 (8 x P-Cores + 8 x E-Cores)
Base Clock Speed	P-Core: 2.1 GHz E-Core: 1.5 GHz
Maximum Boost Speed	P-Core Turbo: 5.1 GHz E-Core Turbo: 4.1 GHz
Thermal Design Power (TDP, Max)	65 W
Included Thermal Solution	Laminar RM1 (65 W)
Integrated Graphics	No



General



CPU Model	Intel Core i7-13700F (13th Gen)
CPU Socket	LGA 1700
Manufacturing Process	10 nm
Maximum CPU Configuration	1S
Maximum Number of PCIe Lanes	16 (Revision 5.0) 4 (Revision 4.0)
Unlocked	No

Performance

Number of Cores	16 (8 x P-Cores + 8 x E-Cores)
Number of Threads	24
Base Clock Speed	P-Core: 2.1 GHz E-Core: 1.5 GHz
Maximum Boost Speed	P-Core Turbo: 5.1 GHz E-Core Turbo: 4.1 GHz
L3 Cache	30 MB

Memory Support

Maximum Capacity	128 GB
Memory Support	DDR5 Up to 5600 MHz DDR4 Up to 3200 MHz
ECC Memory	No
Channel Architecture	Dual Channel
Maximum Memory Bandwidth	89.6 GB/s
Optane Memory Support	Yes



Power



Thermal Design Power (TDP, Max)	65 W
Included Thermal Solution	Laminar RM1 (65 W)
Maximum Temperature	212°F / 100°C
Thermal Monitoring Technologies	Yes



Technology



AES Support	Yes
Extension	AVX 2.0, AVX-512, SSE 4.1/4.2
Instruction Set	64-Bit
Virtualization	Yes: Intel VT-d, Intel VT-x, Intel VT-x with Extended Page Tables (EPT)
DMI	DMI4 (16 GT/s)
vPro Support	No
Performance Technologies	Deep Learning Boost, Gaussian and Neural Accelerator 3.0, Hyper-Threading, Intel Thread Director, SpeedShift, SpeedStep, Turbo Boost 2.0, Turbo Boost Max 3.0
Security Technologies	Control-Flow Enforcement (CET), Device Protection with Boot Guard, Execute Disable Bit, MBE (Mode-Based Execute) Control, OS Guard, Secure Key, Software Guard Extensions, Threat Detection Technology (TDT), Trusted Execution Technology
Integrated Graphics	No



Packaging Info



Package Weight	1.03 lb
Box Dimensions (LxWxH)	5.8 x 4.6 x 3.1"



In the Box



• Intel Core i7-13700F 2.1 GHz 16-Core LGA 1700 Processor
• Intel Laminar RM1 Cooler
• Limited 3-Year Manufacturer Warranty
